DESCRIPTION

Basic Info.

Model NO.	TXSL
IP Rating	IP65
Certification	CE, RoHS, CCC, ISO, EMC
Part6	Solar Controller
Part7	Anchor Bolt
Part5	Battery Box
Part4	Gel/Lithium Battery
Certificate	Ce RoHS
MOQ	1PCS
Warranty	3 Years
Part8	Cable
Height	3m 5m 6m 7m 8m 10m 12m 15m 20m
Thickness	2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5.0mm
Item Name	Wind Solar Hybrid Street Light
Part3	Solar Panel
Part2	Street Light Pole with Bracket
Design	ODM /OEM
Part1	Lamp
Transport Package	Carton, Wooden Case
Specification	450*180*52mm
Trademark	QIXIANG
Origin	China
HS Code	9405409000
Production Capacity	10000/Month

Product Description

Product Description

1,Specification

No	Item	Picture	Parameters
1	TXLED05 Led Lamp		Power:20w/30w/40w/50w/60w/80w/100w/120w/150w Chip:Lumileds/Bridgelux/Cree/Epister Lumens:100-120lm/w Voltage:DC12V/24V Color temperature:3000-6500K
2	Solar Panels		Power:60w/90w/120w/75w*2/90w*2/120w*2/150w*2/180w*2/200w*2 Nominal Voltage:18v Efficiency of solar cells:18% Material:Mono Cells/Poly Cells
3	Battery (Lithium battery available)		Gel Battery :24AH/30AH/40AH/30AH*2/40AH*2/ 50AH*2/65AH*2/80AH*2 Lithium Battery :14AH/22AH/30AH/36AH/42AH/48AH/56AH Type: lead-acid / lithium batteyNominal Voltage:12V/24V
4	Battery Box		Material:Plastic/Steel
5	Controller		Rated Current:10A/15A/20A Nominal Voltage:12V/24V
6	Pole		Height: 5m(A); Diameter: 60/140mm(d/D); Thickness: 3mm(B);Flange Plate:240*12mm(W*T)
			Height: 6m(A); Diameter: 60/140mm(d/D); Thickness: 3mm(B);Flange Plate:240*12mm(W*T)
			Height: 7m(A); Diameter: 70/160mm(d/D); Thickness: 3.5mm(B);Flange Plate:300*14mm(W*T)
			Height: 8m(A); Diameter: 70/160mm(d/D); Thickness: 3.5mm(B);Flange Plate:300*14mm(W*T)
			Height: 9m(A); Diameter: 80/180mm(d/D); Thickness: 4.0mm(B);Flange Plate:350*18mm(W*T)
			Height: 10m(A); Diameter: 80/200mm(d/D); Thickness: 4.0mm(B);Flange Plate:350*18mm(W*T)
7	Anchor Bolt		4-M16;4-M18;4-M20;4-M24
8	Cables		12m/15m/18m/20m/25m/30m
9	Wind Turbine		100w wind turbine for 20w/30w/40w led lamp Rated Voltage:12/24V Packing Size:470*410*330mm Security Wind Speed:35m/s Weight:14kg
			300w wind turbine for 50w/60w/80w/100w led lamp Rated Voltage:12/24V Security wind speed:35m/s G.W:18kg

The configuration above is for your reference,you can reply me your request,or reply me:
(1)The watt of lamp
(2)The working hours that the solar street light need to work every night
(3)Continous rainy and cloudy days

2,Product Description

3,Package and loading

4,Application project

5,Certifications

6,Exhibition

7,FAQ

Q1. Can I have a sample order for led light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for led light?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on led light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
